Description
Medium size case with jam-free purge valve and latches. Soft grip rubber handle reinforced with corrosion proof steel pins. Panel mounting bracket slots.
Imperial Dimensions
| Internal Dimensions | |
|---|---|
| Length | 14 15/16 in |
| Width | 10 5/8 in |
| Depth | 7 1/16 in |
| Lid | 1 7/8 in |
| Base | 5 1/4 in |
| External Dimensions | |
|---|---|
| Length | 16 1/8 in |
| Width | 13 3/8 in |
| Depth | 8 1/16 in |
| Other Data | |
|---|---|
| Weight Empty | 6.92 lbs |
| Weight with Foam | 7.89 lbs |
| Weight with Custom Foam | lbs |
| Volume | 4.75 gal |
| Buoyancy | 27.33 lbs/max |
| Operating temperature °F | min -27.4 / max +194 |
Metric Dimensions
| Internal Dimensions | |
|---|---|
| Length | 380 mm |
| Width | 270 mm |
| Depth | 180 mm |
| Lid | 47 mm |
| Base | 133 mm |
| External Dimensions | |
|---|---|
| Length | 410 mm |
| Width | 340 mm |
| Depth | 205 mm |
| Other Data | |
|---|---|
| Weight Empty | 3.14 Kg |
| Weight with Foam | 3.58 Kg |
| Weight with Custom Foam | Kg |
| Volume | 18.40 lt |
| Buoyancy | 12.40 Kg/max |
| Operating temperature °C | min -33 / max +90 |
Internal Configuration
Black Empty
